Wirings map:
| Wire color | Function description |
|---|---|
| RED | A+ |
| GREEN | A- |
| YELLOW | B+ |
| BLUE | B- |
Wirings map:
| Wire colors | Function description |
|---|---|
| BLACK | A+ |
| GREEN | A- |
| RED | B+ |
| BLUE | B- |
